Product Description
Features of label printer mobile:
• roll diameter: 58 mm
• extreme exquisite lightweight structure design is easy to carry
• easy paper structure is easy to use and maintenance
• equipped with large capacity rechargeable lithium battery 7.4V, 1500 Ma
• 1.2 meters cement ground height of fall
Multiple wired and wireless interfaces optional
• support the client local program upgrade
• equipped with Windows computer end drive
• equipped with WM, WINCE, Symbian, presentation software and dynamic link library Android platform
• Bluetooth host function
Applications:
• copy watch - electrical water meter charge
• Insurance - insurance field fast loss
• warehousing, inventory / distribution / warehousing
• parking - confirm parking time charge of Statistics
• logistics, express transportation invoices / goods delivery order
• mobile sales - ticket / fast consumer goods such as mobile sales
• police and police / management / business field Enforcement / health supervision
Parts list of photo printer
leather belt buckle battery serial line USB interface line • rolls • charger
Detail specification of portable bluetooth thermal photo printer:
| Print line thermal |
| The printing speed of 60 mm / s. |
| Effective print width 58 mm |
| The density of 8 / mm, 384 point / line |
| Printing character ANK: 8 x 16, 12 x 24 GBK:16 x 16, 24 x 24 |
| Characters per line ANK: 48, 32 GBK:24, 16 |
| The paper type thermal label paper |
| Paper width of 30 ~ 60 mm |
| Paper roll diameter: 40 mm |
| Roll core diameter of 15 mm (minimum) |
| Paper thickness 0.12 mm |
| The paper simple paper |
| The life of the printhead 50 kilometers |
| Bar code 1-D:UPC-A, UPC-E, EAN-13, EAN-8, CODE39, ITF25, CODABAR, CODE93, CODE128 |
| 2-D:QR Code |
| ESC/POS instruction set |
| Interface RS-232 port, USB, Bluetooth, infrared |
| Power supply AC00-250V/1.0A |
| DC7.4V battery, rechargeable lithium battery 1.5A |
| The weight of 197 grams (not including rolls, including the battery) |
| Dimensions (WxLxH) 99 x 136.6 x 51 mm |
| Working temperature -10 ~ 50 ° C |
| Storage temperature -20 ~ 70 ° C |
| Work humidity 20 ~ 85% |
| Storage humidity 5 ~ 95% |
